Q35Y-16 Hydraulic Ironworker Combined Punching And Shearing Machine
Q35Y Series multi-function Hydraulic Iron worker is the latest
product of the punching and shearing machine which can cut , punch
, notch and bend all kinds of materials such as plate , flat bar ,
square bar , round bar , equal , angle, channel ,I-beam and so on .
Lifeng Industrial hydraulic ironworkers have been designed and
built to the highest quality standards in the industry.This
profitable machine will serve any grueling fabrication shop for
decades to come.
The machine by the European Union CE certification and ISO quality
system certification
Product Application
Machine is widely uesd in steel , coal , high-speds railway ,
highway , automobile , shipbuilding , electric poower and other
industries and so on .
Main Features
1) Punch hole
2) Cut angle bar
3) Cut round and square bar , channel bar and I-beam
4) Shearing plate
5) Notching
Punching :
Full range of universal punches and dies are available . Unique
style allows for large angle iron punching and large channel
punching .
Large viewing window on stripper swing awat design for ease of
operation . Large two piece gauging table with rulers and stop as
standard fittings . Quick changecoupling nut and sleeve for rapid
replacement of change .
Shearing :
Different size channel and I-beam cutting . Large strong guarding
of max safety .
Round and square bar shear has multiple holes for a variety of
sizes . Adjustable hold down device for round and square bar .
The angle shear has the ability to cut angle at 45º both top and
bottom leg . This gives the operator the ability to make a picture
frame corner for perfect welds . Diamond shaped blade for quality
cuts that is minimal material lost and deformity .
Notching :
Unique design allows for cutting of angle and flat bar . Electrical
interlock safety guard and three gauging stops for precise
positioning .
Notching is a metal-cutting process used on sheet metal or thin
barstock , sometimes on angle sections or tube .
Accessories List :
a. A set of round hole punching die
b. A set of angle steel blade
c. A set of channel blade or round and square bar blade
d. A set of shearing plate blade
e. A set of notching blade
The above moulds will be installed in the machine, safety guards
are also fitted as standard on all working stations. For other dies
and blades, customers need to order and pay additionally.
Parameters:
| Machine Model | Q35Y - 16 |
| Max Shearing Thickness | 16 | mm |
| Max Punching Thickness | 16 | mm |
| Max Punching Diameter | 25 | mm |
| Punching Pressure | 600 | KN |
| Main power | 5.5 | KW |
