Vertical V Grooving Machine,CNC V Cut Machine Sheet Metal 1250x6000
mm
Introduction of Vertical V Groover Machine
The products produced by our company have a high degree of
automation, stable performance, and safe operation. We have
achieved an international leading position in a number of
technologies and gained customer recognition. We also have
professional technical staff to provide you with services to ensure
the normal operation of the equipment. The Vertical V Groover
Machine we produce comply with international standards and are
equipped with professionals to guide the installation. One has been
recognized by hundreds of customers.
Vertical V Groover Machine Characteristics
1. Mainly electrical components are imported, in line with
international standards, safe and reliable, long life,
anti-interference ability, and electric control cabinet is equipped
with heat sink.
2. RGHK high-speed CNC grooving machine for thin plate adopts
precision ball screw as power transmission component, which with
high machining accuracy is especially important for high-grade
products.
3. The CNC system is easy to master and operate. As long as the
processing parameters are input, the equipment will be processed
automatically, and there are multiple interlocking safeguards to
ensure the safe operation of the equipment.
4. There are supporting devices equipped in the front and back of
the workbench to prevent scratching the metal plate material in the
process.
Parameters of V Groover Machines
| NO | NAME | PARAMETER | UNIT |
| 1 | Max. Width of metal sheet | 1250 | mm |
| 2 | Max. Length of metal sheet | 6000 | mm |
| 3 | Max. thickness(Stainless steel) | 6 | mm |
| 4 | Min. Thickness of metal sheet | 0.4 | mm |
| 5 | Min.distance of the V from edge | 10 | mm |
| 6 | Max. cutting speed of X axis | 120 | m/min |
| 7 | Max .return speed of the X axis | 120 | m/min |
| 8 | Max.distance of Y axis | 1250 | mm |
| 9 | Resolution in Y1 axis | 0.001 | mm |
| 10 | Repeated positioning accuracy | ±0.01 | mm |
| 11 | Resolution in z axis | 0.001 | mm |
| 12 | Repeated positioning accuracy | ±0.01 | mm |
| 13 | Motor power | X axis | 5.5 | kw |
| Y axis | 1 |
| Z axis | 1 |
| 14 | Overall dimensions | Length | 7700 | mm |
| Width | 2400 |
| Height | 2110 |
| 15 | Weight | 21 | T |
Advantages of our Vertical V Grooving Machine
1. We are a factory, not a trading company.
2. Equipment manufacturing processes and materials in line with ISO
quality system standards and the European CE system standards.
3. Our factory has ten years of experience in production equipment,
and the technology is very mature.
4. The machine has high safety performance and a long service life.
